Instruction & warranty
Acknowledgement
___________________________________________________________________
Thank you for choosing Marshal Watch. It is assembled using high quality materials and components. It comes with a two (2) years limited warranty from the date of purchase of the Marshal Watch.
This manual will be able to let you understand on how to operate the Marshal Watch.
To ensure that your watch operates with prefect precision in years to come, we advise you to pay attention to the advice given to you in the manual.
Maintenance and Care
We would advise you to clean your watch regularly (except for the leather strap) using a warm cloth. If happen to make contact with seawater, we would advise to rinse the watch with clean water, wipe using a warm cloth and keep it dry.
Do not leave the watch anywhere subjected to strong magnetic and expose to high temperature.
We would advise your Marshal Watch to be serviced every 4 years by the authorised Marshal Watch representative or retailer. To ensure the watch remains with valid warranty, always consult the authorised Marshal Watch representative or retailer.
Replacement of Battery
Upon the battery has been drained, it must be replaced by authorised Marshal Watch representative or retailer without any delay.
The battery will usually last for 2 Years. Marshal watch has a battery saving feature, if you decide not to wear the watch by 3 months, you may pull the crown to 2nd position and 1st position (for Calibre 145 and 121). This will cut the power supply to the watch.
Instruction Manual for Marshal Watch Chronograph
Calibre 10 and 20
Chronograph function: Centred second 1th/1 second. Chronograph timing up to 11 hours 59 minutes and 59 seconds.
_______________________________________________________________
1 Display buttons
2 Time setting
3 Date setting
4 Using of chronograph
5 Chronograph Reset
1 Display Buttons
Calibre 10
Calibre 20
2 Setting of time
1 Pull out the crown to the 2nd position.
2 Turning the crown and adjust the minutes and hour hands.
3 Push down the crown to the original position.
3 Setting of Date
1 Pull out the crown to the 1st position.
2 Turning the crown to adjust the calendar.
* It is advised not to change date between 9:00pm to 1:00am, the date may not change on the next day.
3 Push down the crown to the original position.
4 USING THE CHRONOGRAPH
Measuring time with the chronograph
1 The chronograph can be started and stopped each time by pressing button "A" chronograph is able to measure and display time in 1/1 second united up to maximum of 11 hours 59 minutes 59 seconds.
The chronograph second hand keeps continuously for 11 hours 59 minutes 59 seconds after starting.
2 Pressing button "B" resets the chronograph and the chronograph second hand, chronograph minute hand, and chronograph hour hand returns to zero position.
5 CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY)
This procedure should be performed when the chronograph second hand does not return to zero position after the chronograph has been reset, and including after the battery has been replaced.
1 Pull the crown out to the 2nd position.
2 Press button "A" to set the chronograph second hand to the zero position. The chronograph hand can be advanced rapidly by continuously pressing button "A".
3 Once the hand has been zeroed, return the crown to the normal position.
*Do not push crown to normal position while the chronograph second hand returns to zero position. It stops on the way when crown are returned to normal position and its position is recognized as zero position.
Instruction Manual for Marshal Watch
Calibre 25
Chronograph function: sub-dial 1th/1 second. Chronograph timing up to 29 minutes and 59 seconds.
_______________________________________________________________
1 Display buttons
2 Time setting
3 Date setting
4 Using of chronograph
5 Chronograph Reset
1 Display buttons
Calibre 25
2 Setting of time
1 Pull out the crown to the 2nd position.
2 Turning the crown and adjust the minutes and hour hands.
3 Push down the crown to the original position.
3 Setting of Date
1 Pull out the crown to the 1st position.
2 Turning the crown to adjust the calendar.
* It is advised not to change date between 9:00pm to 1:00am, the date may not change on the next day.
3 Push down the crown to the original position.
4 Using of Chronograph
Measuring time with the chronograph
1 The chronograph can be started and stopped each time by pressing button "A" chronograph is able to measure and display time in 1/1 second united up to maximum of 29 minutes 59 seconds.
The chronograph second hand keeps continuously for 29 minutes 59 seconds after starting.
2 Pressing button "B" resets the chronograph and the chronograph second hand, chronograph minute hand, and chronograph hour hand returns to zero position.
5 Chronograph Reset
This procedure should be performed when the chronograph second hand does not return to zero position after the chronograph has been reset, and including after the battery has been replaced.
1 Pull the crown out to the 2nd position.
2 Press button "A" to set the chronograph second hand to the zero position. The chronograph hand can be advanced rapidly by continuously pressing button "A".
3 Once the hand has been zeroed, return the crown to the normal position.
*Do not push crown to normal position while the chronograph second hand returns to zero position. It stops on the way when crown are returned to normal position and its position is recognized as zero position.
Instruction Manual for Marshal Watch
Calibre 121/ 133
Quartz 3 Hands with date / 2 Hands without date
_______________________________________________________________
1 Display buttons
2 Time setting
3 Date setting
1 Display buttons
Calibre 121
Calibre 131
2 Time setting
1 Pull the crown from its normal position to the 2nd position for calibre 131 and 1st position for calibre 121.
2 Turn the crown to adjust the minute and hour hands.
3 Push the crown back to its original position.
3 Date setting (applicable to calibre 131 movement)
1 Pull the crown from its original position to the 1st position.
2 Turn the crown to adjust the date.
3 Push the crown back to its original position.
Instruction Manual for Marshal Watch
Calibre 145
Quartz 2 Hands with a miniature second hand
______________________________________________________________________
1 Display buttons
2 Time setting
1 Display Button
Calibre 145
2 Time setting
1 Pull out the crown from the normal position to 1st position.
2 Adjust the hours and minutes hand by turning the crown.
3 Push the crown back to the original position.
Instruction Manual for Marshal Watch
OLED
______________________________________________________________________
Functions of the watch
-
Time Local
-
Calendar
-
Themometer
-
Stopwatch
-
Countdown Mode
-
Alarm
-
Second Time Zone
1. Time (Local)
Press S2 for the watch to switch on to display timing.
Adjustment of the time, press S2 longer and “12H” will blink, then press S2 and set the time by pressing S1 to change the value. Press S2 to change the setting from SS to HH and MM. Repeats the same step till the time is set.
2. Calendar
After setting of Time, press S2 again to set the calendar.
In the setting of YY-MM-DD format by pressing S1 to set into the selected numbers and S2 to change into next.
3. Themometer
Temperature of the surrounding. This will be automatic adjust based on the watch sensor.
4. Stopwatch
Press S1 to start the stopwatch and stop the stopwatch. Press S2 for a long time to reset the stopwatch counter.
5. Countdown Mode
By default, it is set at 10 minutes and count down. Press S1 to start and stop the function
Press S2 for a long time to set the count down timer to your desire time and with press S1 to set the value. Beep sound will be produced to complete the process.
6. Alarm
Press S2 longer to activate the alarm and adjust the timing with the press of S1
button and press S2 to set between HH and MM.
7. Dual Time
Press S2 for long and that will be in adjustment mode. The numbers will blink and press S1 to set the number for HH:MM:SS and selection of the AM and PM. Beep sounds will be produced to confirm the setting.
Water Resistant
Marshal Watch
Warranty Term and Condition
Your Marshal watch is warranted by Marshal Watch Company LLC for a period of Twenty-four (24) Months or 2 Years from the date of purchase under the term and conditions of this warranty. The warranty covers the material and manufacturing defects existing at the time of delivery of the purchased Marshal Watch. The warranty is only valid with date and stamped with a valid stamp of the Marshal watch retailer.
During the warranty period and by presenting the valid warranty card, you will have the right to get the defected parts repaired.
The warranty does not include the
-The life of battery
-Normal and wear and tear and aging. (i.e. scratched dial, damaged to bracelet, scratched glass, alternation of colour on the bracelets and casings.)
- Any damage caused or resulting from abnormal, abusive use, lack of care, negligence, accident and incorrect use of the watch.
Replacement of battery
It is recommended to be done at the authorized Marshal Watch retailers and Marshal watch service centre. A worn off battery is to be replaced immediately as to reduce the risk of leakage resulting damage to the movement.
Marshal Watch Service Centres Address
Asia
(Singapore)
Vincent Watch Private Limited
311 New Upper Changi Road, Bedok Mall
#01-28 Singapore 467360
North America
Marshal Watch Company LLC
2215-B Renaissance Drive
Las Vegas NV 89119
